Summary

Features

• 1) Support Ethernet and WIFI simultaneous access.
• 2) Wide voltage power supply: 9~48V supply scope
• 3) Support three forms of serial port: RS232/485/422
• 4) No packet loss.
• 5) Sticky package optimization, the real-time of serial framing is strong. The serial packet sub-package interval of ordinary WIFI serial port server is over 100ms, ZLAN7104 is optional 1ms~100ms, resolution precision is greatly improved.
• 6) Support upgrading program through Ethernet port in the system. Support remote network upgrades.
• 7) Support configuring WEB custom download. Can be configured to the user’s own web pages.
• 8) Support wifi connection between modules.
• 9) Support hardware flow control CTS/RTS and Software flow control XON/XOFF.
• 10) Power input mode optional: can choose industrial terminal power supply or ordinary power adapter plugs.
• 11) Provide 4 kinds LINK indicator interface.
• 12) Auto-adapt serial port parameters.
• 13) One-key search configuration. Using ZLVircom software to one-key search and configure device parameters. Also can use WEB to configure parameters.
• 14) Provide serial port control command, can configure multiple parameters one time.
• 15) Support DNS, support as a DHCP client, as a AP mode can also be as a DHCP Server.
• 16) Provide advanced function modules: 7044 support Modbus TCP converting to RTU and multiple host access to wifi Modbus gateway module. 7104N is a wifi module supporting p2p.
• 17) Support TCP sever, TCP client, UDP/UDP multicast.
• 18) Can equip long lead WiFi antenna, to conveniently install on metal chassis external surface.
• 19) Provide reset button. Can reset WiFi parameter and IP address of module.
• 20) The internal integrate real-time operating system, fast start.
• 21) Embedded 485 lightning protection function, suitable for outdoor 485 communication.
• 22) High strong anti-electromagnetic interference. The outer use anti-radiation SECC board.
